Machine C Manual Functions.  (C) FWD activates blue Infeed Rollers in the forward direction (moves material from C to D).  (C) REV activates Infeed Rollers in the reverse direction (from D to C).  PRESS BAR activates Flange Bar on Machine C.  PRESS SEAL activates Heat Sealing Bar.  PRESS PUSH UP activates PushUp Bar on Machine C.  CUTTER MOTOR FWD moves Eastman cutter from home position (corner of Machine A and Machine C) to end of cut location near intersection of Machine C and machine B).  To turn OFF forward movement, click on FWD again.  CUTTER MOTOR REV reverses movement of the cutter back to home cutter home position.  CUTTER BLADE turns cutter blade ON.  ROTOMATION activates Rotomation folding device.  FLIPPER activates finger which enables folding on Machine C.  GRIPPER closes the Grippers at home position on Machines A & B.  PUMP MOTOR activates vacuum system on Machine C.
